Features

Up to 11.3Gb/s data links

Single +3.3V power supply

Hot-pluggable SFP+ footprint

Up to 80km on 9/125µm SMF

Metal enclosure, for lower EMI

RoHS-10 compliant and lead-free

Support Digital Monitoring interface

Duplex LC/UPC type pluggable optical interface

Meet ESD requirements, resist 8KV direct contact voltage

50 GHz ITU channel spacing with integrated wavelength locker

Smart Features: Self-Negotiation, Remote DDM, Remote WL Locking

Monolithically integrated full C-band tunable transmitter and APD receiver

Compliant with SFF+MSA and SFF-8472 SFF-8431, SFF-8690 and G.698.1

Case operating temperature Commercial: 0 ~ +70oC Extended: -10 ~ +80oC Industrial: -40 ~ +85oC

Applications

10G CPRI, eCPRI

DWDM CSTM-64

10G Fiber Channel

DWDM 10GBASE-ZR/ZW & 10G Ethernet

Wavelength Selection: C-band λc Wavelength Guide Pin Descriptions

Absolute Maximum Ratings

It has to be noted that the operation in excess of any individual absolute maximum ratings might cause permanent damage to this module.

Recommended Operating Conditions

General Description

HC -ALT81x tunable transceiver is an integrated fiber optic transceiver that provides a high-speed serial link at signaling rates from 9.95 Gb/s to 11.3 Gb/s. The module complies with the 10 Gigabit Enhanced Small Form Factor Pluggable （SFP+）multisource agreement-MSA

（SFF-8431） and SFF-8432，SFF-8690，SFF-8472. It complies with the ITU-T G.698.1 standard with 50 GHz channel spacing for SONET/SDH, IEEE DWDM 10GBASE-ZR for 80 km reach (Ethernet), and DWDM 10GFC for 80 km reach (Fiber Channel) applications.

The transceiver integrates the receiver and transmitter path on one module. The transceiver contains a C-band-tunable integrated Mach-Zehnder (MZ) laser, enabling data transmission over single-mode fiber through an industry-standard LC connector. On the receiver side, the 10 G/bps data stream is recovered from an APD/ trans-impedance amplifier, and passed to an output driver.

This module features a hot-pluggable electrical interface.

HC-ALT81x transceivers provide a unique enhanced digital diagnostic monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, and received optical power and transceiver supply voltage. It also defines a sophisticated system of alarm and warning flags, which alerts end-users when particular operating parameters are outside of a factory set normal range.

The SFP+ MSA defines a 256-byte memory map in EEPROM that is accessible over a 2-wire serial interface at the 8bit address 1010000X (A0h). The digital diagnostic monitoring interface makes use of the 8bit address 1010001X (A2h), so the originally defined serial ID memory map remains unchanged.

      Pin Assignment and Pin Description

Figure1. Diagram of host board connector block pin numbers and names

 Notes:

1. Circuit ground is internally isolated from chassis ground.
2. Internally pulled down per SFF-8431 Rev 4.1.
3. Laser output disabled on TDIS >2.0V or open, enabled on TDIS<0.8V.
4. Should be pulled up with 4.7kΩ-10kΩ on host board to a voltage between 2.0V and 3.6V. MOD_ABS pulls line low to indicate module is plugged in.
5. LOS is open collector output. It should be pulled up with 4.7kΩ-10kΩ on host board to a voltage between 2.0V and 3.6V. Logic 0 indicates normal operation; logic 1 indicates loss of signal.
6. TFAULT is an open collector/drain output, which should be pulled up with a 4.7kΩ-10kΩ resistor on the host board if intended for use. Pull up voltage should be between 2.0V to Vcc + 0.3V.A high output indicates a transmitter fault caused by either the TX bias current or the TX output power exceeding the preset alarm thresholds. A low output indicates normal operation. In the low state, the output is pulled to<0.8V.

Electrical Characteristics

The following electrical characteristics are defined over the Recommended Operating Environment unless otherwise specified.

Notes:

1.   Or open circuit.
2. These are unfiltered 20-80% values.
3. Input 100 ohms differential termination.
4. Connected directly to TX data input pins. AC coupled thereafter.
5. Loss of Signal is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.

Receiver sensitivity is compliant with power supply sinusoidal modulation of 20 Hz to 1.5 MHz up to specified value applied through the recommended power supply filtering network

     Optical Characteristics

The following optical characteristics are defined over the Recommended Operating Environment unless otherwise specified.

  Notes:

1.  corresponds to approximately 0.4 nm.

2.  Class 1 Laser Safety per FDA/CDRH and IEC-825-1 regulations.

3.  Measured with Light source 1529.16~1567.13nm, ER>8.2dB; BER≤1E-12 @PRBS=2³¹ -1 NRZ.

Digital Diagnostic Functions

The following digital diagnostic characteristics are defined over the Recommended Operating Environment unless otherwise specified. It is compliant to SFF-8472 Rev10.2 with internal calibration mode. For external calibration mode please contact our sales staff.

Mechanical Dimensions

Figure2. Mechanical Outline

      Ordering Information
