SOA pulse modulation and amplification module
Product introduction
HC-PLM series pulse modulation and amplification module integrates semiconductor optical amplifier (SOA), pulse erbium-doped fiber amplifier (EDFA) and its supporting temperature control and modulation circuits, and can output optical pulse signals with the narrowest pulse width of 2 ns and peak power of 100 W. At the same time, a built-in pulse signal source can be selected, which has the characteristics of fast rise time, high pulse extinction ratio, good stability and convenient use, so that it becomes an ideal choice for generating and amplifying pulsed light in various optical fiber sensing systems, and can also be applied to quantum communication systems, semiconductor testing and other aspects.
Product features
Software-adjustable pulse width
Rise/fall time < 2 ns
Adjustment range 5 ns ~ 500 ns
Repetition frequency 1Hz-1MHz
Integrating SOA and EDFA
Lectable electric pulse sources
Optional Raman Optical Amplifier 500 mW
Output peak power < 1 W
High extinction ratio
DC 5V power supply
RS232 serial communication
Upper computer control
Module encapsulation
Scope of application
DVS & DAS System
BOTDR & BOTDA System
Homodyne coherent detection system
Technical parameters
|
Parameter |
Symbol |
Unit |
Minimum value |
Typical value |
Maximum value |
|
|
SOA pulse modulation section |
||||||
|
Optical parameters |
||||||
|
Operating wavelength |
lc |
nm |
1550.12 |
|||
|
Input optical power |
Po |
dBm |
-5 |
|
7 |
|
|
Rise time |
tr |
ns |
|
2 |
|
|
|
Pulse width range |
|
ns |
5 |
|
500 |
|
|
Extinction ratio |
ER |
dB |
50 |
|
|
|
|
Input electrical signal |
High level |
Vh |
V |
2 |
3.3/5 |
|
|
Low level |
Vl |
V |
0 |
|
0.8 |
|
|
Pulse signal source (optional) |
||||||
|
Pulse width |
PW |
ns |
5 |
|
500 |
|
|
Rise time |
Tr |
ns |
1 |
|
1000 |
|
|
Repeat frequency |
F |
Hz |
1 |
|
100K |
|
|
Synchronization and output signal format |
|
|
|
LVTTL |
|
|
|
Pulse amplification section |
||||||
|
Operating wavelength |
lc |
nm |
|
1550.12 |
|
|
|
Output optical peak power |
Pp |
mW |
10 |
|
1000 |
|
|
Gain * * |
G |
dB |
|
30 |
50 |
|
|
Noise Index * * * |
NF |
dB |
|
|
5.0 |
|
|
Output optical power stability |
DP |
dB |
|
|
±0.1 |
|
|
Input/output optical isolation |
ISO |
dB |
30 |
|
|
|
|
Return loss |
RL |
dB |
30 |
|
|
|
|
Polarization dependent gain |
PDG |
dB |
|
0.3 |
0.5 |
|
|
Polarization mode dispersion |
PMD |
ps |
|
|
0.3 |
|
|
Input pump leakage |
PL_in |
dBm |
|
|
-30 |
|
|
Leakage of output pump |
PL_out |
dBm |
|
|
-40 |
|
|
Working mode |
|
|
|
ACC |
|
|
|
Raman amplification section (optional) |
||||||
|
Operating wavelength |
lc |
nm |
|
1455 |
|
|
|
Output optical power |
Po |
mW |
|
500 |
|
|
|
Optical power stability |
DP |
dB |
|
|
0.02 |
|
|
Working mode |
|
|
|
ACC |
|
|
|
Other parameters |
||||||
|
Operating voltage |
Vo |
V |
4.75 |
5 |
5.25 |
|
|
Operating current |
-- |
Io |
A |
|
0.5 1.8 |
1.5 3 |
|
Integrated Raman amplifier |
||||||
|
Operating temperature |
To |
℃ |
-20 |
|
60 |
|
|
Storage temperature |
Ts |
℃ |
-40 |
|
80 |
|
|
Interface type |
||||||
|
Fiber type |
|
|
SMF-28e |
|||
|
Fiber optic interface |
|
|
FC flange interface |
|||
|
Fiber optic connector |
|
|
FC/APC |
|||
|
Electrical signal interface |
|
|
SMF(f) |
|||
|
Power supply |
|
|
Through-core capacitor |
|||
|
Communication |
|
|
RS232 serial communication |
|||
|
Mechanical dimensions |
||||||
|
Package size |
-- |
|
mm |
160x120x19 |
||
|
Integrated Raman amplifier |
|
mm |
180x150x20 |
|||
Test curve
Figure 1 200ns Pulse Waveform and DVS System Test Chart (Coherent Heterodyne Detection)
Schematic diagram
Mechanical dimensions in mm
Ordering Information HC-PLM-XXX-PS
XXX — SEA — SOA integrated EDFA; SELA — SOA integrated EDFA and Raman amplifier;
PS-- NC — integrated pulse source not required; PS ：built-in pulse source
if you need more supports, please contact us.
