PD （Photodetecor)
The PD detector is internally packaged with high performance InGaAs/InP PIN photodiode.Based on its special optical design, the product has the advantages of high responsiveness, low dark current and high reliability.Due to its compact structure and small volume, it is easy to be integrated in high-density optical fiber communication systems.
Features
Low dark current
Compact structure
High degree of response
Application
Fiber amplifier
Power monitoring
WDM transmission system
Technical Parameter
|
Parameter |
Unit |
Value |
|
Operating Wavelength |
nm |
1250~1650 |
|
Responsivity (Dual fiber) |
mA/mW |
≥0.85 |
|
Dark Current |
nA |
≤1.0 (@25°C, 5V) |
|
Forward Current |
mA |
≤10 |
|
Reverse Voltage |
V |
≤5 |
|
Capacitance |
pF |
≤6 (Vr=5V, f=1MHz) |
|
Return Loss |
dB |
≥45 |
|
Polarization Dependent Loss |
dB |
≤0.15 |
|
Polarization Mode Dispersion |
ps |
≤0.1 |
|
Temperature Dependent Rate |
% |
±5 (@Responsivity) |
|
Fiber Type |
/ |
G657A1/A2/B3 or with 0.9mm Loose tube |
|
Operating Temperature |
℃ |
-5~+70 |
|
Storage temperature |
℃ |
-40~+85 |
Remark: 1. The reliability test conformed the Telcordia GR-1221-CORE.
2. Specifications without connector.
Size /Dimension (mm)
P1:Regular size
P2:MINI size
Order information: HC－PD-A-B-C-D-E
|
A |
B |
C |
D |
E |
|
Packagesize |
Working wavelength |
Optical fiber type |
Fiber length |
Connector |
|
N:Φ5.5×21 |
1310: 1310nm |
25：Ø0.25mm |
05: 0.5m |
00: None |
|
M:Φ3.0×18 |
1550: 1550nm |
90：Ø0.9mm |
10: 1.0m |
FP: FC/UPC |
|
X：other |
1315: 1310/1550nm |
X：other |
15: 1.5m |
FA: FC/APC |
|
|
X：other |
|
X: other |
SP: SC/UPC |
|
|
|
|
|
SA: SC/APC |
|
|
|
|
|
LP: LC/UPC |
|
|
|
|
|
LA: LC/APC |
|
|
|
|
|
X: other |
If you need more support , Please contact us.
