2U Rack-Mounted 8-Group 1X6 Optical Switch

Rack Mount Optical Switches provide compact, rack-mounted solutions for flexible and reliable optical switching in modern fiber networks. The category includes Optical Circuit Switches (OCS) for large-scale connectivity, Wavelength Selective Switches (WSS) for DWDM and ROADM applications, MEMS Optical Switches for high-speed, high-density switching, and Mechanical Optical Switches for stable and cost-effective fiber control. Ideal for telecom networks, data centers, and DCI deployments.

Specification

Resources

Product introduction

Optical switch is a kind of optical path control device, which plays the role of controlling and converting the optical path. And play an important role in optical communication application. The optical switch is mainly used in multi-channel optical monitoring, LAN multi-light source/detector automatic switching and optical sensing multi-point dynamic monitoring system in the optical transmission system, optical fiber, optical device, network and field engineering optical cable test in the optical test system; Optical device assembly and adjustment.

Product features

It has the characteristics of low insertion loss and fast switching speed.

The LCD display screen is used to display data intuitively and facilitate the user's operation.

Light path switching can be set through panel keys and serial port commands. And that key operation can be loc through a serial port instruction.

Technical parameters

Model	FSW8-1X61D-1U433
Operating wavelength	850nm
Test wavelength	850nm
Insertion loss	≤2.0 dB
Repeatability	≤±0.05 dB
Return loss	≥30dB
Crosstalk	≥30dB
Polarization dependent loss	≤0.05dB
Switching time	≤ 10ms (adjacent sequential switching)
Fiber type	MM（OM3）
Connector form	LC/PC
Monitoring port	RJ45、RS-232
Working power supply	Dual AC: 85 ~ 264 V (50/60Hz)
Operating temperature	-5 ～ + 60℃
Storage temperature	-40 ～ + 80°C
Chassis type	19-inch standard 2U rack (483 × 303 × 89mm) RAL9002

Front panel description

Front panel

RJ45 Ethernet interface, RS-232 serial port: communication interface for equipment monitoring data information.

LCD display: display of equipment address, current channel and related information.

▲ — — Move up key; ▼-Move down key; Enter-Enter key; Esc-Cancel key.

Power indicator lamp Power 1, Power2: working power indicator.

Optical interface description: the COM port on the equipment panel is the common port, and 1, 2, 3, 4, 5 and 6 are the channel numbers respectively.

Back panel description

Back panel

AC power interface: AC power input interface for equipment operation.

Schematic of internal optical path

Schematic of internal optical path of single 1 × 6 optical switch (same for other 1 × 6)
