1030nm 100W Polarization dependent Free Space isolator

Application : High-power laser systems, ultrafast laser amplifier systems, precision measurement and cold atom physics, space optical path experimental platforms

Specification

Resources

This LG series are designed for preventing back reflection. The high isolation, low insertion loss and large aperture features make it flexible to fit different applications.

Specifications

Parameter	Unit	Value
Center Wavelength (λc)	nm	1030 or Specified
Operating Range	nm	λc±10
Peak Transmission	%	>90
Peak Isolation (λc)	dB	>30
Input Polarization		Specified by ordering info
Output Polarization		Specified by ordering info
Minimum. Optical Average Power Damage Threshold	W	Specified by ordering info 10 J/cm2 @ 10 ns 1 J/cm2 @ 8 ps
Operating Temperature	℃	10 to 30
Storage temperature	℃	0 to 60

Package Dimension

Ordering Information HC-LG-①-②-③③③③-④-⑤-⑥⑥-⑦⑦

①

②

③③③③

④

⑤

⑥⑥

⑦⑦

Type

Bandwidth

Wavelength

Aperture

Power Handling

Input Polarization

Output Polarization

I - Isolator

R - Rotator

F - Fixed Narrowband

B - Broadband

S - Specified

1030 - 1030nm

SSSS - Specify

3 - Φ3.0 mm

5 - Φ5.0 mm

S - Specify

100 - 100W

S - Specified

00 - 0 Degree (Horizontal)

45 - 45 Degree

90 - 90 Degree

(Vertical)

SS - Specify

00 - 0 Degree (Horizontal)

45 - 45Degree

90 - 90Degree (Vertical)

SS - Specify

If you need more support , Please contact us .
