1064nm 230W Polarization dependent Free-Space isolator
|
Parameter |
Unit |
Value |
|
Operating Range |
nm |
1060 or specified |
|
Operating Range |
nm
|
λc ± 5 |
|
Peak Transmission |
%
|
> 92 |
|
Peak Isolation (λc) |
dB
|
> 33 |
|
Input Polarization |
|
Specified by ordering info |
|
Output Polarization |
|
Specified by ordering info |
|
Minimum. Optical Average Power |
|
Specified by ordering info |
|
Operating Temperature |
℃
|
+ 10 to + 30 |
|
Storage temperature |
℃
|
0 to + 60 |
Package Dimension
Ordering Information HC-LG-I-F-①①①①-②-③③③-④④-⑤⑤
|
①①①① |
② |
③③③ |
④④ |
⑤⑤ |
|
Wavelength |
Aperture(>5mm) |
Power Handling |
Input Polarization |
Output Polarization |
|
1060-1060nm
SSSS-Specify
|
10-Φ10.0mm
S-Specify
|
230-230W
SSS-Specify
|
00-0Degree(Horizontal)
90-90Degree(Vertical)
SS-Specify
|
00-0Degree(Horizontal)
45-45Degree
90-90Degree(Vertical)
SS-Specify
|
If you need more support , Please contact us .
