16/18CH CCWDM Module(Industrial Grade)

The 18CH CCWDM module achieves efficient transmission of multi-wavelength signals through wavelength division multiplexing technology, which is widely used in telecommunication, data centre, enterprise network, fibre-optic sensing, monitoring system and industrial communication, etc., to enhance the transmission capacity and efficiency of fibre-optic networks.

Specification

Resources

Features

Compact size

Wide Passband

Low Insertion Loss

High Channel Isolation

Epoxy free on optical path

High Stability and reliability

Applications

Line Monitoring

WDM Network

Telecommunication

Cellular Application

Fiber Optical Amplifier

Access Network

Technical Parameters

Parameters		Specification
Channel Number		16CH	18CH
channel Wavelength（nm）		1270-1610 or 1271-1611
Channel Spacing（nm）		20
Passband（nm）		+/-6.5
Isolation（dB）	Adjacent	>30
	Non-adjacent	>45
Insertion Loss（dB）		≤3.3
PDL(dB)		≤0.2
Directivity(dB)		≥55
Return Loss（dB）		≥50
PMD(ps)		≤0.2
Maximum Power Handling (mW)		500
Opterating Temperature (℃)		-40~+85
Storage Temperature (℃)		-40~+85
Fiber Type		Corning SMF-28e,900um Loose Tube
Package dimension (mm)		50.0x50.0x6.0

Above specifications are for devices without connector.

Typical Spectrum
