High Power Polarization Insensitive fiber Isolator
Description
The High Power Polarization Insensitive Isolator is characterized with low insertion loss,high isolation, high power handling, high return loss, excellent environmental stability and reliability. The High Power Polarization Insensitive Isolator is ideal for fiber lasers and instrumentation applications.
Key Features
Low Insertion Loss
High Isolation
Applications
Fiber Lasers
Fiber Optic Instruments
Specifications
|
Parameter
|
Unit |
Value |
||
|
Center Wavelength (λc) |
nm |
1064 |
||
|
Operating Wavelength Range |
nm |
λc ± 10 |
||
|
Min. Isolation, λc, @ All Polarization States, 23 ℃ |
dB |
25 |
||
|
Typ. Insertion Loss, 23 ℃ |
dB |
0.5 |
||
|
Max. Insertion Loss, 23 ℃ |
dB |
0.8 |
||
|
Max. Polarization Dependent Loss |
dB |
0.2 |
||
|
Min. Return Loss (Input/Output) |
dB |
45/45 |
||
|
Max. Average Optical Power |
W |
50 |
||
|
Max. Peak Power (Pulse Width, 10 ns) |
kW |
20 |
||
|
Max. Tensile Load |
N |
5 |
||
|
Fiber Type |
- |
Specified by ordering info |
||
|
Operating Temperature |
℃ |
+ 10 to + 50 |
||
|
Storage Temperature |
℃ |
0 to + 60 |
||
Package Dimensions
Ordering Information
|
HC-HI-①①-②②-③-④-⑤-⑥-⑦ |
|||||
|
①①: Wavelength |
②②: Handling Power |
③: Connector Type |
|
④: Fiber Jacket |
|
|
06 - 1064 nm |
50 - 50 W |
N - None |
|
B - Bare Fiber |
|
|
SS - Specify |
SS - Specify |
|
|
L - 900 μm Loose Tube |
|
|
|
|
|
|
S - Specify |
|
|
⑤: Fiber Length |
⑥: Fiber Type |
|
|
⑦: Power Type |
|
|
1 - 1.0 m |
1 - Corning HI1060 Fiber |
3 - Nufern LMA-GDF-20/130-M |
P - Pulsed |
||
|
S - Specify |
2 - Nufern FUD-3584 Fiber |
S - Specify |
|
C - Continuous Wave |
|
