532nm/633nm Circulator
Product Features
Low Insertion Loss
Low Return Loss
High Isolation
High Stability& Reliability
Application Scope
Optical Fiber Amplifier
Test Instrument
Optical Fiber Sensing
Medical Equipment
Technical Specifications
|
Parameters |
Unit |
Value |
|
Port Type |
|
3 Port |
|
Center Wavelength |
nm |
532,633 |
|
Operating Wavelength Range |
nm |
±5 |
|
Typical Peak Isolation |
dB |
22 |
|
Minimum Isolation@23℃ |
dB |
20 |
|
Typical Insertion Loss@23℃ |
dB |
1.5 |
|
High Insertion Loss@23 ℃ |
dB |
2 0 |
|
Minimum Extinction Ratio@23℃( Polarization-Maintaining Fiber Type) |
dB |
20 |
|
Maximum Polarization Dependent Loss@23℃ (Single-Mode Fiber Type) |
dB |
0.15 |
|
Minimum Return Loss (Input / Output) |
dB |
40 |
|
Minimum Crosstalk |
dB |
40 |
|
Maximum Average Power(Including Port1,2 |
W |
0 .5,1,2 |
|
Maximum Peak Power for ns pulse |
kW |
10 or Specified |
|
Maximum Tensile Load |
N |
5 |
|
Package Dimensions |
mm |
49x28x26 |
|
Operating Temperature |
℃ |
+10~+50 |
|
Storage Temperature |
℃ |
0~+60 |
Note:
When connectors are used, the power handling is only 1W, insertion loss increases by 0.3dB, return loss decreases by 5dB, and extinction ratio decreases by 2dB. The connector key is aligned with the slow axis.
Package Dimensions(Unit：mm)
Ordering Information：HC-CIR-A-B-C-D-E-F-G-H-I
|
A |
B |
C |
D |
E |
F |
G |
H |
I |
|
Wavelength |
Average Power |
Peak Power |
Operating Axis |
Package Dimensions |
Fiber Type |
Pigtail Type |
Fiber Length |
Connector Type |
|
532=532nm
633=633nm
X=Others |
50=500mW
01=1W
02=2W
|
00=Continuous Wave
01=1kW
02=2kW
05=5kW
X=Others |
B=Biaxial Operation
F=Fast Axis Blocked
N=Non-PM |
1=44x28x26mm
X=Others
|
PM63=PM630-HP
460=460-HP
PM46=PM460-HP
630=630-HP
X=Others |
0=250um Bare Fiber
1=900um Loose Tube
|
08=0.8m
10=1.0m
X=Others |
FP=FC/UPC FA=FC/APC SP=SC/UPC SA=SC/APC 00=None X=Others |
If you need more support , Please contact us .
