Features
High Return Loss
Low Insertion Loss
High Extinction Ratio
High Stability& Reliability
Application
Testing Instrument
Optical Fiber Sensing
Product Developmen
Communication System
Technical Specifications
|
Parameters |
Unit |
Value |
|
Center Wavelength |
nm |
532,633 |
|
Operating Wavelength Range |
nm |
±10 |
|
Typical Insertion Loss@23 ℃ |
dB |
1.3 |
|
Maximum Insertion Loss@23 ℃ |
dB |
1.5 |
|
Minimum Return Loss |
dB |
50 |
|
Typical Extinction Ratio@23℃ |
dB |
24 |
|
Minimum Extinction Ratio@23 ℃ |
dB |
22 |
|
Input/Output Fiber Type |
/ |
SM→SM or SM→PM or PM→PM |
|
Maximum Optical Power (CW) |
mW |
300 |
|
Maximum Tensile Load |
N |
5 |
|
Operating Temperature |
℃ |
-5~+70 |
|
Storage Temperature |
℃ |
-40~+85 |
Note:
When connectors are used, the power handling is only 1W, insertion loss increases by 0.3dB, return loss decreases by 5dB, and extinction ratio decreases by 2dB. The connector key is aligned with the slow axis.
Dimensions(Unit：mm)
Ordering Information HC-ILP-A-B-C-D-E-F-G-H-I-J
|
A |
B |
C |
D |
E |
|
Wavelength |
Fiber Type |
Operating Axis |
Input Fiber Type |
Output Fiber Type |
|
532=532nm
633=633nm
X=Others |
1=SM-SM
2=SM-PM
3=PM-PM
|
F=Fast axis blocked
N=Non-PM |
PM63=PM630-HP
460=460-HP
PM46=PM460-HP
630=630-HP
X=Others
|
PM63=PM630-HP460=460- HP
PM46=PM460-HP460=630- HP
X=Others |
|
F |
G |
H |
I |
J |
|
Package Dimensions |
Pigtail Type |
Fiber Length |
Input Connector Type |
Output Connector Type |
|
1=33x17x11.5mm
X=Others |
0=Bare Fiber
1=900μm Loose Tube |
08=0.8m
10=1m
X=Others |
FP=FC/UPC
FA=FC/APC
SP=SC/UPC
SA=SC/APC
00=None
X=Others |
FP=FC/UPC
FA=FC/APC
SP=SC/UPC
SA=SC/APC
00=None
X=Others |
If you need more support , Please contact us.
