Polarization independent Fiber optic Isolator 900nm
The High Power Polarization Insensitive Fiber Optic Isolator is characterized with low insertion loss, high isolation, high power handling, high return loss, excellent environmental stability and reliability. It is ideal for fiber laser and instrumentation applications.
Specifications
|
Parameter |
Unit |
Value |
|
|
Center Wavelength (λc) |
nm |
915 |
|
|
Operating Wavelength Range |
nm |
λc ± 10 |
|
|
Max. Polarization Dependent Loss |
dB |
0.2 |
|
|
Min. Isolation, λc, 23 ℃, all polarization states |
dB |
22 |
|
|
Typ. Insertion Loss, 23 ℃ |
dB |
1.5 |
|
|
Max. Insertion Loss, 23 ℃ |
dB |
1.8 |
|
|
Min. Return Loss (Input/Output) |
dB |
45/45 |
|
|
Max. Optical Power (Continuous Wave) |
W |
2 |
|
|
Max. Peak Power for ns Pulse |
kW |
10 |
|
|
Max. Tensile Load |
N |
5 |
|
|
Fiber Type |
|
Specified by ordering info |
|
|
Operating Temperature |
℃ |
10 to +50 |
|
|
Storage Temperature |
℃ |
0 to +60 |
|
*IL is 0.5 dB higher, and RL is 5 dB lower for each connector added.
** The optical power handling capability will be max 1W when the isolator is terminated with connectors.
Package Dimensions
Ordering Information HC-HI-①①①-②②-③-④-⑤-⑥-⑦
|
①①①: Wavelength |
②②: Handling Power |
③: Connector Type |
④: Fiber Jacket |
|
|
915 - 915 nm |
3X - 300 mW |
1 - FC/UPC |
4 - SC/APC |
B - 250 μm bare fiber |
|
SSS - Specify |
02 - 2 W |
2 - FC/APC |
N - None |
L - 900 μm loose tube |
|
|
SS - Specify |
3 - SC/UPC |
S - Specify |
S - Specify |
|
1 - 1 m |
1 - HI 1060 fiber |
P - Pulse Application |
|
|
|
SS - Specify |
2 - 780 HP fiber |
C - Continuous Wave |
|
|
|
|
S - Specify |
|
|
|
