16×16 MEMS matrix optical switch module
Features
Low crosstalk
Modular design
Low insertion loss
Wavelength range
High stability and reliability
Applications
System monitoring
Optical fiber sensing
Configuration is high
Laboratory development
Multiple light monitoring
Metropolitan area network
Remote optical fiber monitoring system
Technical Parameters
|
Type no. |
HC-MEMS-M-16X16 |
|
Working wavelength |
1260-1650nm |
|
Test the wavelength |
1550nm |
|
Insertion loss |
≤3dB |
|
Return loss |
≥45dB |
|
crosstalk |
≥50dB |
|
Polarization dependent loss |
＜0.3dB |
|
Switch time |
≤10ms |
|
Transmitted optical power |
≤23dBm |
|
Optical fiber type |
SM-9/125 |
|
Optical interface type |
FC/APC |
|
The degree of long |
1.00 m 0.9 mm casing |
|
Control interface |
RS232 |
|
Working voltage |
DC5V |
|
Power consumption |
≤10W |
|
Working temperature |
-5℃ ~ +70℃ |
|
Storage temperature |
-40℃ ~ +85℃ |
|
Module size |
200x180x18mm |
Optical Path Diagram
Module Dimension (mm)
Pin definition
|
Pin# |
Signal name |
Type |
Description |
|
|
1 |
2 |
VCC |
Power |
+5VDC , Digital power supply |
|
3 |
4 |
GND |
Power |
Digital ground |
|
5 |
TXD |
Output |
Transmit Data |
|
|
6 |
RXD |
Input |
Receive Data |
|
|
7 |
8 |
GND |
Power |
Digital ground |
|
9、10、11、12、 13、14、15、16、17、18,19、20 |
NC |
|
|
|
