3 Ports FWDM (Multi-Mode)

Through three-port design and thin-film filter technology, it achieves multiplexing and demultiplexing of dual-wavelength signals with low insertion loss, high isolation and compact design, etc. It is widely used in the fields of fibre-to-the-home, cable TV, fibre-optic sensing, monitoring system, industrial communication and telecommunication network, etc., which improves the transmission efficiency and reliability of fibre-optic network.

Specification

Resources

Features

Low Insertion Loss

Ultra Flat Wide Passband

High Channel Isolation

High Stability and reliability

Epoxy-free on Optical Path

Wide Operating Wavelength Range

Applications

MAN

CATV System

WDM System

FTTH Tri-Play System

Testing Instruments

Technical Specification

Parameter		Wavelength division multiplexer（MM）
Transmission wavelength range (nm)		850±50
Reflected wavelength range (nm)		1310±50
Insertion Loss (dB)	Transmission Channel	≤1.3
	Reflection channel	≤1.0
Isolation	Transmission Channel	>30
	Reflection channel	>15
Polarization Dependent Loss (dB)		<0.2
Polarization mode dispersion (PS)		<0.2
Directivity (dB)		>35
Return loss (dB)		>30
Maximum light passing power (mW)		300
Fiber type		Multimode fiber
Fiber length		1M
Operating temperature (℃)		-10~+70
Storage temperature (℃)		-40~+85
Package size (mm)		Φ5.5x38 for 900um Loose tube

*1、Above specifications are for devices without connector.

2、Specifications may change without notice.

Dimension (Unit:mm)

Ordering Information HC－FWDM－A－B－C－D

Wavelength

Fiber Type

Fiber Length

Connector

85/13=850 pass/1310reflect

1=Bare fiber

2=900um loose tube

1=1m

2=2m

0=None

1=FC/APC

2=FC/PC

3=SC/APC

4=SC/PC

5=ST

6=LC

S=Specify

If you need more support , Please contact us .
